    首页 >> 产品中心 >>激光管与激光光纤模块 >>激光光纤耦合模块 >> 多模激光光纤耦合激520nm 绿色光雷达激光测距 同轴封装光纤激光器
    详细说明

    多模激光光纤耦合激520nm 绿色光雷达激光测距 同轴封装光纤激光器

    • 商品说明

    大功率绿色光纤耦合激光器 520NM 30MW激光器 激光二极管

    品牌:STARSEALAND

    型号:XL-C520-30MW

    产品类型:激光管

    工作温度范围:-10—70(℃)

    向电压:2.2V

    额定电流:20


    该产品应用于光测量,条形码扫描器,以及电信开关、数据通讯网络、自由空间数据传输、光存储、激光打印机、dvd播放器、安保光屏障、测量设备、光电控制、流体及气体监测、荧光治疗、印刷机械,光复印和荧光检测、眼科学等等,欢迎咨询!


    激光耦合器
    激光耦合

    激光耦合1

    Parameter

    Symbol

    Ratings

    Unit

    Optical output

    Po

    0.99

    W

    Operating temp.

    Top

    25

    Storage temp.

    Tstg

    -40 ~ 90



    Parameter

    Symbol

    Min.

    Typ.

    Max.

    Unit

    Optical Output Power

    Po

    -

    30

    35

    MW

    Lasing Wavelength

    λ

    515

    520

    525

    nm

    Spectral Width (FWHM)

    Δλ


    5


    nm

    Threshold Current

    Ith


    25


    mA

    Operating Current

    Iop

    -

    110


    mA

    Operating Voltage

    Vop


    7

     9

    V

    Divergence Angle

    θ ⊥ ×θ ∥
          29×8
          Deg






    *1All above values are evaluated under 10W optical power output

    *2:  θ ⊥ ×θ ∥are defined as full width at half maximum.

    Note : Tc = Case (Stem) temperature
